| SIZE |
D |
Grip Range
e |
h
Ref. |
d0
+0.15
-0.05 |
d
+0.03
-0.20 |
dk
±0.30 |
K
±0.20 |
L
±0.30 |
| PL-M4 |
M4 |
0.5-2.5 |
6.5 |
6 |
6 |
9 |
0.8 |
10.8 |
| PL-M5 |
M5 |
0.5-3.0 |
8.0 |
7 |
7 |
10 |
1.0 |
13.0 |
| PL-M6 |
M6 |
0.5-3.5 |
8.5 |
9 |
9 |
13 |
1.5 |
15.8 |
| PL-M8 |
M8 |
0.5-3.5 |
10.5 |
11 |
11 |
15 |
1.5 |
18.0 |
| PL-M10 |
M10 |
0.5-3.5 |
12.0 |
12 |
12 |
17 |
1.8 |
20.3 |
| PL-M12 |
M10 |
0.5-3.5 |
16.0 |
15 |
15 |
19 |
1.8 |
24.3 |
|
|
| |
|
|
|
