材质
铆体: 5056 Alu.Alloy
钉芯: Steel |
表面颜色
铆体:
Polished
钉芯: Zinc Plated |
| |
|
D1
NOM. |
DRILL NO. &HOLE
SIZE |
ART. CODE |
GRIP RANGE |
L (MAX) |
D
NOM. |
K
MAX |
P
MIN. |
SHEAR
LBS |
TENSILE
LBS |
| INCH |
MM |
INCH |
MM |
3/32"
2.4mm |
#41
2.5-2.6 |
5-AS32 |
0.020-0.125 |
0.5-3.2 |
0.250 |
6.4 |
0.188"
4.8 |
0.032"
0.81 |
1.00"
25.4 |
90
400N |
120
535N |
| 5-AS34 |
0.126-0.250 |
3.2-6.4 |
0.375 |
9.5 |
| 5-AS36 |
0.251-0.375 |
6.4-9.5 |
0.500 |
12.7 |
1/8"
3.2mm |
#30
3.3-3.4 |
5-AS41 |
0.020-0.062 |
0.5-1.6 |
0.212 |
5.4 |
0.250"
6.4 |
0.040"
1.02 |
1.06"
27 |
170
760N |
220
980N |
| 5-AS42 |
0.063-0.125 |
1.6-3.2 |
0.275 |
7.0 |
| 5-AS43 |
0.126-0.187 |
3.2-4.8 |
0.337 |
8.6 |
| 5-AS44 |
0.188-0.250 |
4.8-6.4 |
0.400 |
10.2 |
| 5-AS45 |
0.251-0.312 |
6.4-7.9 |
0.462 |
11.7 |
| 5-AS46 |
0.313-0.375 |
7.9-9.5 |
0.525 |
13.3 |
| 5-AS48 |
0.376-0.500 |
9.5-12.7 |
0.650 |
16.5 |
| 5-AS410 |
0.501-0.625 |
12.7-15.9 |
0.755 |
19.7 |
5/32"
4.0mm |
#20
4.2-4.2 |
5-AS52 |
0.020-0.125 |
0.5-3.2 |
0.300 |
7.6 |
0.312"
7.9 |
0.050"
1.27 |
1.06"
27 |
260
1160N |
350
1560N |
| 5-AS53 |
0.126-0.187 |
3.2-4.8 |
0.362 |
9.2 |
| 5-AS54 |
0.188-0.250 |
4.8-6.4 |
0.425 |
10.8 |
| 5-AS56 |
0.251-0.375 |
6.4-9.5 |
0.550 |
14.0 |
| 5-AS58 |
0.376-0.500 |
9.5-12.7 |
0.675 |
17.1 |
| 5-AS510 |
0.501-0.625 |
12.7-15.9 |
0.800 |
20.3 |
| 5-AS516 |
0.876-1.000 |
22.2-25.4 |
1.175 |
29.8 |
3/16"
4.8mm |
#11
4.9-5.0 |
5-AS62 |
0.020-0.125 |
0.5-3.2 |
0.325 |
8.3 |
0.375"
9.5 |
0.060"
1.52 |
1.06"
27 |
380
1700N |
500
2230N |
| 5-AS63 |
0.126-0.187 |
3.2-4.8 |
0.387 |
9.8 |
| 5-AS64 |
0.188-0.250 |
4.8-6.4 |
0.450 |
11.4 |
| 5-AS66 |
0.251-0.375 |
6.4-9.5 |
0.575 |
14.6 |
| 5-AS68 |
0.376-0.500 |
9.5-12.7 |
0.700 |
17.8 |
| 5-AS610 |
0.501-0.625 |
12.7-15.9 |
0.825 |
21.0 |
| 5-AS612 |
0.626-0.750 |
15.9-19.1 |
0.950 |
24.1 |
| 5-AS614 |
0.751-0.875 |
19.1-22.2 |
1.075 |
27.3 |
| 5-AS616 |
0.876-1.000 |
22.2-25.4 |
1.200 |
30.5 |
| 5-AS618 |
1.001-1.125 |
25.4-29.6 |
1.325 |
33.7 |
| 5-AS622 |
1.251-1.375 |
31.8-34-.9 |
1.575 |
40.0 |
1/4"
6.4mm |
F
6.5-6.6 |
5-AS82 |
0.020-0.125 |
0.5-3.2 |
0.375 |
9.5 |
0.500"
12.7
|
0.080"
2.03 |
1.25"
32 |
700
3120N |
920
4100N |
| 5-AS84 |
0.126-0.250 |
3.2-6.4 |
0.500 |
12.7 |
| 5-AS86 |
0.251-0.375 |
6.4-9.5 |
0.625 |
15.9 |
| 5-AS88 |
0.376-0.500 |
9.5-12.7 |
0.750 |
19.1 |
| 5-AS810 |
0.501-0.625 |
12.7-15.9 |
0.875 |
22.2 |
| 5-AS812 |
0.626-0.750 |
15.9-19.1 |
1.000 |
25.4 |
| 5-AS814 |
0.751-0.875 |
19.1-22.2 |
1.125 |
28.6 |
| 5-AS816 |
0.876-1.000 |
22.2-25.4 |
1.250 |
31.8 |
| 5-AS818 |
1.001-1.125 |
25.4-28.6 |
1.375 |
34.9 |
|
|
|
